Compact Electrolytic Sewage Treatment Plant
WHY
Electrolytic Sewage Treatment Plant is an evolving and emerging field in the treatment of waste water. It is unconventional non biological & chemical free technology. It has the potential to treat effectively the waste water compared to conventional treatment. It has potential to remove even non biological & toxics companiment from the waste streams. The system are compact modular in construction, packaged & noiseless on operation.
An Electrolytic Sewage Treatment Plant - Sewage Water Treatment Plant/STP Plant/Sewage Treatment Plant is a modern, eco-friendly wastewater treatment system that utilizes electrolysis to treat sewage and wastewater. In this process, an electrical current is passed through the wastewater to facilitate chemical reactions that break down pollutants, remove harmful substances like heavy metals, bacteria, and pathogens, and reduce the overall contamination levels.
The electrolysis process leads to the formation of flocs and the production of chlorine, which helps disinfect the water. The system is highly efficient, uses less space compared to traditional methods, and often operates with lower energy consumption. It is increasingly used in urban areas and industries as a sustainable solution to manage and treat sewage cost-effectively, ensuring cleaner water and a healthier environment.
ELECTROLYSIS PROCESS
Electrolysis is a technique involving the passage of electricity through the effluent. The electrical current destabilizes dissolved colloidal particles and alters the charge on suspended particles permitting purification of water.
ELECTRO COAGULATION :
Reactions at the electrodes in Electro coagulation :
Reaction at the anode :
Me(s) — (3e-) = Me3+(aq)
Me3+(aq) + 3H20 = Me(OH)3 + 3H+
Reaction at the cathode :
2H20 + 2e- > H2 + 20H-
SPECIAL FEATURES OF ELECTROLYSIS
- The design uses a unique bipolar technology
- It is modular in construction
- It can be designed for either batch or continuous operation
- 4. It is custom designed & easily expandable
- It can be retrofitted in the existing facility
- Pollution removal rates in most cases - more than 95%
GENERAL SPECIFICATION:
| Sr. No | Parameters | Inlet | Outlet After |
|---|---|---|---|
| 1 | pH | 7.0 | 7.0 |
| 2 | TSS | 200-300 | < 10 ppm |
| 3 | BOD | 250-350 | < 30 ppm |
| 4 | COD | 400-500 | < 100 ppm |
Comparison: For Sewage Treatment:
Electrolysis Process V/s Conventional Biological Activated Sludge Process
Electrolysis Process
- Does not generate greenhouse gases
- Does not deplete atmospheric oxygen
- Emits low carbon
- Non chemical, non-biological process
- No need to maintain biomass, ph, temperature
- Accelerated start up
- Conserves more water due to better quality treatment
- hock load can be easily tackled
- Independent of toxicity
- Noiseless
- Generates less sludge with better dewatering
- Easily expandable
- Ease of operation and maintenance Less moving parts, less maintenance
- High performance to cost ratio
Conventional Biological Activated Sludge Process
- Generates greenhouse gases
- Deplete atmospheric oxygen (microbiological process)
- Emits carbon Needs chemicals for disinfection
- Needs to maintain biomass, pH, temperature
- Prolonged startup period
- Conserves less water due to poor quality treatment
- Shock load cannot be tackled Toxicity destroys microbes, restoration takes time
- Noisy because of aerators (associated drive)
- Generates more sludge with lower dewatering
- Difficult to expand
- Difficult to operate and maintain
- More moving parts, more maintenance Low performance to cost ration
BT Water Treatment Pvt. Ltd. has been providing Leading-edge Electrolytic Sewage Treatment Plants - STP Plant for many years, delivering efficient and eco-friendly solutions for wastewater management. Our team of highly experienced engineers ensures that each plant is designed and implemented with precision, using the latest technology to meet the specific needs of our clients.
We are a specialized STP Manufacturer for delivering Electrolytic STP, which utilizes advanced electrolysis processes to treat sewage, remove contaminants, and purify water effectively. This technology is energy-efficient and environmentally sustainable, offering a reliable alternative to traditional treatment methods.
At BT Water Treatment Pvt. Ltd., we take pride in our commitment to quality and performance, ensuring that every project is executed competently and to the highest standards. Our team’s expertise and experience make us a trusted partner in providing seamless and effective sewage treatment solutions.
